Business
| Standard Pack | 20 | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Coil Type | Non Latching | Coil Power | 220 mW |
| Coil Current | 13.88 mA | Release Time | 5ms |
| Power - Input | 247 | Voltage - Core | 4000 |
| Voltage Rating | 250 | Coil Resistance | 1.296 KOhm |
| Current - Surge | 8 | Voltage - Supply | 18 V |
| Switching Voltage | 400VAC - Max | Switching Capacity | 2000VA |
| Vgs(th) (Max) @ Id | 1.8 VDC | Connector Impedance | 1 Form C (CO) |
| Current - Trip (It) | 8 | Current Rating (Max) | 8 A |
| Frequency - Output 1 | 单稳态、直流 | Current - Max/Contact | 8A |
| Current Rating (Amps) | 5 – 10, 16 | Insulation Resistance | 8 mm [ .315 in ] |
| Vce(on) (Max) @ Vge, Ic | 12.6 VDC | Contact Rating (Current) | 8A |
| Current - Discharge (Max) (8/20uS) | 8 | Voltage - Anode - Cathode (Vak)(Max) | 400 |
| AC contacts rating (at resistance load) | 8 A / 250 VAC | DC contacts rating (at resistance load) | 8 A / 30 VDC |
Mechanical
| Width | 10.1 mm [ .398 in ] | Height | 12.3 mm [ .484 in ] |
| Length | 28.5 mm [ 1.122 in ] | Weight | 9.6 g |
| Packaging | Bulk | Insulation | 继电器基极 PTI250 的跟踪指数 |
| Size - Body | 28.5 x 10.1 x 12.3mm | Contact Form | SPDT (1 Form C) |
| Height (Max) | 12 – 13 | Pitch - Post | 3.2mm |
| Mounting Type | Through Hole | Contact Material | Silver Cadmium Oxide |
| Size / Dimension | see | Insulation Height | 5.5 – 8 |
| Termination Style | PC Pin | Number of Contacts | 1 |
| Insulation Diameter | 8 mm [ .315 in ] | Width / Cross Section | 10 – 12 |
| Contact Layout, Typical | SPDT | Supplier Device Package | Hermetic seal |
| 1st Connector Mounting Type | 印刷电路板 | ||
Product Info
| Type | Industrial Relay | Features | Sealed - Fully |
| Relay Type | General Purpose | Relay Variant | miniature |
| Number of Units | 1 | Contacts Configuration | SPDT |
Environmental
| Operate Time | 9ms | Mechanical Life | 30000000cycles |
| Ingress Protection | RTIII | Operating Temperature | -40°C ~ 70°C |
| Initial Dielectric Strength | 1000 | ||
