Business
| MOQ | 500 | Product | Trimmer Resistors - Multi Turn |
| Unit Pack | 50 | Other Names | T93YA-20K |
| Product Category | Trimmer Resistors - Through Hole | Standard Package | Rail / Tube |
| Factory Pack Quantity | 500 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85334010 | Rad Hardened | No |
| Military Standard | Not Required | ||
Electrical
| Tolerance | 10 % | Resistance | 20 KOhm |
| Element Type | Cermet | Power (Watts) | 0.5W, 1/2W |
| Power - Rated | 1/2 W | Voltage Rating | 250 V |
| Voltage - Rated | 250V | Resistance (Ohms) | 20k |
| Contact Resistance | :2% | Voltage - Breakdown | :1000V |
| Resistance Tolerance | 20kΩ | Resistor - Base (R1) | :Radial Leaded |
| DC Resistance (DCR) (Max) | :20kohm | ||
Mechanical
| Depth | 5mm | Taper | Linear |
| Height | 11mm | Length | 9.7mm |
| Torque | 1,5Ncm | Weight | 0.0012 |
| Diameter | Not Required mm | Base Type | :Through Hole |
| Packaging | Tube | Size - Body | 9.8 x 9.8 x 5mm |
| Mounting Type | Through Hole | Terminal Type | :PCB Terminals |
| Mounting Style | Through Hole | Shaft Diameter | 2.2 mm |
| Length - Overall | 9.7 mm | Material - Blade | Cermet |
| Package Quantity | 50 | Size / Dimension | Square - 0.382" L x 0.197" W x 0.386" H (9.70mm x 5.00mm x 9.80mm) |
| Pitch - Connector | 2.5mm | Termination Style | Pin |
| Conductor Material | cermet | Resistive Material | Cermet |
Product Info
| Spg | 50 | Type | Trimmer |
| Series | T93 | DELETED | Compliant |
| Schematic | see | Technology | Cermet |
| Failure Rate | Not Required | Product Type | Multi-Turn |
| Adjustment Type | Top Adjustment | Characteristics | linear |
| Number of Turns | 21(Elec)|23(Mech) Turns | Number of Units | 1 |
| Type Attributes | 3/8" | ||
Environmental
| NEMA Frame Size | :IP67 | Ingress Protection | IP67 |
| Operating Temperature | -55 to 155 °C | Temperature Coefficient | ±100ppm/°C |
| Temperature Coefficient (Typ) | :100ppm/°C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- t93.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
