132134

Business

Product	PCB Connectors	Other Names	ACX1230
Part # Aliases	319-0176 99H5021	Product Category	RF Connectors / Coaxial Connectors
Standard Package	1

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Tariff No	85366910

Frequency	0 to 18G	Impedance	50 Ohm
Coupling Factor	Threaded	Frequency - Max	18GHz

Depth	7	Height	9.53
Length	0.531 in.	Weight	0.054322 oz
Packaging	Bulk	Cable Type	:-
Body Finish	Gold	Orientation	Straight
Termination	Solder	Body Material	Brass
Housing Color	Gold	Mounting Type	Through Hole
Angle of Throw	Straight	Connector Type	Jack, Female Socket
Contact Finish	Gold	Fastening Type	Threaded
Housing Finish	Gold	Plating - Body	Gold
Connector Style	SMA	Connector Usage	Threaded
Contact Material	Beryllium Copper	Housing Material	Brass
Length - Overall	7	Primary Material	SMA
Termination Style	PCB - Through Hole	Shield Termination	Solder
Contact Termination	Solder	Dielectric Material	Polytetrafluoroethylene (PTFE)
Insulation Material	Polytetrafluoroethylene	Center Contact Plating	Gold
Center Contact Material	Beryllium Copper	Supplier Device Package	Straight
1st Connector Mounting Type	:PCB
