ADUM3160BRWZ
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 47 |
| Standard Package Name | SOIC W | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
Electrical
| Output | Buffer | Data Rate | 12Mbps |
| Output Type | Logic | Data Rate (Max) | 12 Mbps |
| Current - Output | :6mA | Number of Inputs | 2 |
| Voltage - Supply | 3 to 5.5 V | Propagation Delay | 70ns |
| Number of Channels | 4 | Voltage - Isolation | 2500 V |
| Delay Time - Propagation | 70 ns | Propagation Delay tpLH / tpHL (Max) | 70 ns |
Mechanical
| Weight | 0.000175 | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Style | SMD/SMT |
| Number of Pins | :16 | Package / Case | 16SOIC W |
| Material Finish | :MSL 1 - Unlimited | Package Quantity | SOIC W |
| Number of Positions | 16 | Supplier Device Package | 16-SOIC W |
Product Info
| Series | ADUM3160 | Base Unit | :3160 |
| Inputs - Side 1/Side 2 | 2/2 | ||
Environmental
| Operating Temperature | -40 to 105 °C | ||
Documents & Media
.jpg&w=3840&q=75)
Sourcing & traceability
- Datasheet
- ADuM3160.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
