SS-6566-FLS
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 35 | ||
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85369010 |
| Approval Agency | :CSA, UL | Material Flammability Rating | :UL94V-0 |
Electrical
| Voltage Rating | :30V | Voltage - Supply | :FCC docket 20780 |
| Contact Resistance | :10mohm | Dielectric Strength | :1000V |
| Current Rating (Max) | :1.5A | Insulation Resistance | :500Mohm |
Mechanical
| Depth | :16.36mm | Width | :16mm |
| Length | :16.51mm | Weight | 0.052 |
| Material | :Polyester | LED Color | Does Not Contain LED |
| Packaging | Tray | Shielding | Unshielded |
| Orientation | Vertical | Termination | Solder |
| Mounting Type | Through Hole | Tab Direction | User Selectable |
| Connector Type | Jack | Contact Finish | Gold |
| Number of Rows | 1 | Plating - Body | :Gold |
| Contact Material | Copper Alloy | Housing Material | Thermoplastic |
| Color - Connectors | :Black | Number of Contacts | :6 |
| Contact Termination | :Through Hole Vertical | Number of Positions | :6 |
| Contact Finish Thickness | 30µin (0.76µm) | ||
Product Info
| Gender | :Socket | Series | :- |
| Features | Board Lock, Panel Stops | Number of Ports | 1 |
| Number of Positions/Contacts | 6p6c (RJ11, RJ12, RJ14, RJ25) | ||
Environmental
| Mating Cycles | :1000 | ||
