JN1-22-22S-PKG100

Manufacturer	Japan Aviation Electronics Industry, Ltd.
Description	Standard Circular Contacts 22p contacts for JN1/2 series CONTACT SKT CRIMP 21-25AWG GOLD JN1andJN2StandardCircular22pConnectors(PricedasPackof100) LOOSE SOCKET CONTACT 25-21AWG
Category	连接器解决方案接触件接触件（通用）

对参数有疑问？问 AI 助手

商业参数

产品类别	Standard Circular Contacts	标准包装数量	100
工厂包装数量	100

合规参数

RoHS	RoHS Compliant	汽车级	NO
无铅定义	RoHS-conform

电气参数

最大额定电流

JN1/JN2

机械参数

尺寸	22	材料（通用）	CopperAlloy
包装方式	Bulk	导线线规	21-25 AWG
触头类型	STRAIGHT	插针或插孔	Socket
接触镀层	Gold	主要材料	Contact
第一触头极性	Socket (Female)	接触件端接	Crimp
接触镀层厚度	3.9µin (0.10µm)	线规或范围 - AWG	25 TO 21
触点材料 - 镀层	CRIMP

产品信息

类型

Socket

系列

JN1 / JN2

环境参数

工作温度

GOLD

Documents & Media

PDF Document

JN1 Series Datasheet

PDF Document

JN1-22-2yS-x10000 Drawing
