03-09-2061

Business

Tradename	Standard .093 in	Part # Aliases	0003092061 1261-P 3092061
Product Category	Pin & Socket Connectors	Factory Pack Quantity	1500

RoHS	RoHS Compliant	Tariff No	85369010
Approval Agency Marking	CSA, UL	Material Flammability Rating	:UL94V-2

Color	Natural	Pitch	5.03mm
Weight	0.004	Material	:Clear nylon
Wire Gauge	:0.597mm²	Termination	Crimp
Mounting Type	Straight	Release Force	:0.027N
Angle of Throw	Straight	Number of Rows	2
Package / Case	:Plug	Insertion Force	:0.034N
Material - Body	:Nylon (Polyamide)	Housing Material	Nylon
Length - Overall	1 "	Termination Style	Crimp
1st Contact Gender	Pin (Male), Socket (Female)	Number of Contacts	6
Panel Cutout Shape	:19.05x17.65mm	Number of Positions	:6
Mounting Hole Diameter	0.75×0.695 "	Wire Gauge or Range - mm2	:1.68mm²
Diameter - Outside, Non-Expanded	:4.06mm

Type	Panel Plug	Gender	Male
Series	1261	CAD Drawing	3D CAD Model
Manufacturer	1261 Series	Product Type	Plug Housings
For Use With/Related Products	:1189, 1190, 1380, 1381, 1434, 1434, Crimp Terminals
