点击放大查看
AXK5S30047YG
| Manufacturer | |
| Description | 基板間およびメザニンコネクタ CONN SOCKET BRD/BRD 30 POS 0.5mm Conn Board to Board SKT 30 POS 0.5mm Solder ST SMD Embossed T/R CONN SOCKET P5KS .5MM 30POS SMD Board to Board & Mezzanine Connectors CONN SOCKET BRD/BRD 30 POS 0.5mm AXK5S,P5KS,Socket,0.5mmpitch,30-pin,Ni-barrier,,RoHSconforming, |
| Category |
商业参数
| 其他名称 | 255-2564-2 | 标准包装数量 | 1,000 |
| 工厂包装数量 | 1500 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
电气参数
| 额定电压 | 60 V | 接触电阻 | 60 |
| 最大额定电流 | 500 mA | 最小输入电压 | 60VDC|60VAC |
机械参数
| 深度 | 4.6 | 间距 | 0.020" (0.50mm) |
| 高度 | 3.05 | 包装方式 | Embossed Tape and Reel |
| 端接方式 | Solder | 安装类型 | Surface Mount |
| 连接器类型 | Socket, Center Strip Contacts | 接触镀层 | Gold Over Nickel |
| 排数 | 2 | 堆叠方法 | 4 mm |
| 触头材料 | Copper Alloy | 壳体材料 | Resin |
| 总长度 | 10.7 | 端接样式 | SMD |
| 板面高度 | 0.120" (3.05mm) | 触点数 | 30 |
| 位数 | 30 | 配接堆叠高度 | 4mm, 5mm, 6mm |
产品信息
| 类型 | Board to Board | 连接器性别 | SKT |
| 系列 | P5 | 产品子类型 | Sockets |
