640456-7

Business

Product Category	Headers & Wire Housings	Standard Package	Bulk
Factory Pack Quantity	2000

RoHS	Lead free / RoHS Compliant	Standards	RoHSCompliant,ELVCompliant,UL94V-0
Tariff No	85369010	Leadfree Defin	Wave solder capable to 240Â°C, Wave solder capable to 260Â°C, Wave solder c
Approval Agency	CSA,UL	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Color	Natural	Depth	5.72 mm
Pitch	2.54 mm	Height	10.03 mm
Weight	0.007	Packaging	Bulk
Port Size	0.025in.	Shrouding	No
Orientation	straight	Termination	Solder
Contact Type	Male Pin	Lead Spacing	:2.54mm
Length - Pin	0.14"	Pitch - Post	2.54mm
Polarization	Polarizing Slot	2nd Connector	With
Contact Shape	Square	Housing Color	White
Mounting Type	Vertical	Angle of Throw	Straight
Connector Type	Header, Unshrouded	Contact Finish	Tin
Fastening Type	Friction Lock	Mounting Style	Through Hole
Number of Rows	1	Connector Usage	Header
Locking Feature	Friction Lock	Contact Material	Copper Alloy
Housing Material	Polyester	Length - Overall	17.78 mm
Mounting Feature	Without	Package Quantity	100
Panel Mount Type	Without	Primary Material	InterconnectSystem
Size / Dimension	0.64 [.025]	Connector - Cable	socket
Pin Hole Diameter	0.1"	Termination Style	Through Hole
1st Contact Gender	Pin (Male)	Mating Orientation	With
Number of Contacts	7	Contact Termination	:Through Hole Vertical
Number of Positions	7	Backshell Interrupts	Without
Center Contact Plating	0.100in.	Length - Post (Mating)	0.14in.
Mounting Hole Diameter	0.04"	Contact Length - Mating	0.295" (7.49mm)
Contact Material - Post	Copper Alloy	Termination Post Length	3.56 [0.140]
Small Diameter Recovered	No	Contact Material - Plating	tinned
1st Connector Mounting Feature	1x7
