点击放大查看

165X14839XE

Manufacturer	CONEC Elektronische Bauelemente GmbH
Description	D-Sub Backshells HOOD 25 POS Connector Accessories Water Resistant D-SUB Hood Polybutylene Terephthalate Black With Jack Screw CONN HOOD DSUB 25POS IP67 BLACK
Category	连接器解决方案D-Sub连接器

对参数有疑问？问 AI 助手

商业参数

其他名称	626-1175	产品类别	D-Sub Backshells
标准包装数量	1

合规参数

RoHS

RoHS Compliant

欧盟RoHS

Compliant

机械参数

颜色	Black	深度	91.7
高度	26.5	材料（通用）	Polybutylene Terephthalate, Glass Filled
屏蔽	Unshielded	出线方向	180°
电缆类型	Round	外壳尺寸	3
电缆直径	6 mm to 12 mm	电缆端类型	Straight
外壳材料（壳体）	Glass Filled Polybutylene Terephthalate (PBT)	总长度	62.8
位数	25	电缆对数	1

产品信息

类型	Hood	产品特性	Dust Tight/Waterproof (IP67), Mating Screws 4-40
硬件配件	Cable Clamp	附件类型	One Piece Backshell

Documents & Media

PDF Document

64b9ed5323a7863165224db91773ba39_037.pdf

PDF Document

Install Water Resistant Hoods

PDF Document

D-SUB Plastic Hood IP67
