132C10029X

Manufacturer	CONEC Elektronische Bauelemente GmbH
Description	D-Sub Contacts HIGH POWER CONTACT 20A SOLDER CUP FM Contact SKT Solder Cup ST Cable Mount CONN SOCKET COMBO-D 12-14AWG SLD 132C10029X Contact; female; 12÷14AWG; gold plated; soldering; for cable; 20A
Category	连接器解决方案接触件接触件（通用）

对参数有疑问？问 AI 助手

商业参数

其他名称	626-1145	产品类别	D-Sub Contacts
标准包装数量	100

合规参数

RoHS

RoHS Compliant

欧盟RoHS

Compliant

电气参数

最大额定电流

20 A

连接器类型 - 电压输入

Solder Cup

机械参数

深度	5.5	高度	5.5
重量	1.91 g	直径	2.7mm
包装方式	Bulk	导线线规	14-12
屏蔽类型	No	端接方式	Solder Cup
触点形式	Machined	触头类型	Machined Contacts
触点形状	Machined	安装类型	Cable Mount
连接器类型	Connector D-Subminiature	接触镀层	Gold
安装样式	for cable	触头材料	Copper Alloy
总长度	22.98	包装数量	1
尺寸/外形	see	连接器 - 电缆	contact
端接样式	Solder	第一触头极性	Socket (Female)
端接表面处理	Gold	接触件端接	Solder Cup
接触镀层厚度	30µin (0.76µm)	触点材料 - 镀层	gold plated
端接镀层厚度	Flash

产品信息

SPG	1	类型	Power
连接器性别	SKT	系列	132C
单元数量	1

环境参数

工作温度

-55...155°C

Documents & Media

PDF Document

13K1IE4A.pdf
